Miniature - Aluminium
Part Number: CFDRL55 & CFDRL56
Filter and regulator consolidated in a single assembly (CFDR55M or CFDR56M); wick-feed lubricator (L50) Inline mounting. High-strength polycarbonate plastic bowls; optional aluminum bowls. Piston-type regulator (CFDRL55 models) or diaphragm-type (CFDRL56 models). Self-relieving regulator; non-relieving optional. Pressure gauge. NPTF port threads; optional BSPP threads.
Ambient/Media Temperature: Plastic bowl: 40° to 125°C, Metal bowl: 40° to 175°C
Body: Aluminum for filter/regulator and lubricator
Bowl: 2-Ounce (60-ml) capacity polycarbonate plastic bowls or aluminum bowls
Filter Drain: Internal automatic drain; optional manual drain
Filter Element: 5-µm-rated polyethylene; optional 5-µm, 20-µm, or 40-µm sintered bronze
Fluid Media: Compressed air
Inlet Pressure: 15psig (1bar) minimum with auto drain, Plastic bowls: 150psig (10bar) max, Metal bowls: 200psig (13.7bar) max
Oil Adjustment: External; tamper resistant
Outlet Pressure: Adjustable up to 100 psig (7 bar)
Pressure Gauge: 0 to 160 psig (10.3 bar); 1/8 NPT gauge ports front and rear
Panel Mounting: 1-3/16 inch (30mm) hole required
Regulator Dome and Knob: Acetal
Seals: Nitrile

Sentry Modular
Part Number: VCFDRL10, VCFDRL11 (1/8" & 1/4")
Filter and regulator consolidated in a single assembly (CFDR10M or CFDR11M); wick-feed lubricator (L10); lockout valve (V10). Modular assembly and mounting. Threaded ports or quick-connect fittings for tubing up to 10mm in diameter.5-µm-rated polyethylene filter element; optional sintered bronze elements. High-strength polycarbonate plastic bowls or aluminum bowls. Internal automatic filter drain; optional manual drain. Piston-type regulator (CFDRL10 models) or diaphragm-type (CFDRL11 models). Self-relieving regulator; non-relieving optional. Pressure gauge. NPTF port threads; optional BSPP threads.
Ambient/Media Temperature: 4° to 52°C
Bowl: 60ml capacity polycarbonate plastic bowls or aluminum bowls
Filter Drain: Internal automatic drain; optional manual drain
Filter Element: 5-µm-rated polyethylene; optional 5-µm, 20-µm, or 40-µm sintered bronze
Filter/Regulator & Lubricator Bodies: Acetal
Fluid Media: Compressed air
Inlet Pressure: 15psig (1bar) minimum with automatic drain 150psig (10bar) max
Oil Adjustment: External, no shutoff
Outlet Pressure: Adjustable up to 100 psig (7bar)
Pressure Gauge: 0 to 160psig (10.3bar); 1/8 NPT gauge ports front and rear
Panel Mounting: 1-3/16 inch (30mm) hole required
Regulator Dome and Knob: Acetal
Seals: Nitrile

350 Series CFRL Modular
Part Number: BAGV3A0B6A13 (1/4", 3/8", 1/2")
GENERAL
• Modular or inline mounting
• Compatible with modular 380 series of products
• NPTF port threads; optional BSPP threads
• Front mounted modular clamping design with encapsulated screws
• Polycarbonate bowl with shatterguard; optional metal bowl with nylon sight glass
• Inlet pressure rated at 250psig (17bar) with metal bowls up to 79°C
INTEGRAL FILTER/REGULATOR
• Designed to remove particulate material down to 5 micron from the airstream to protect downstream equipment
• Optional bronze 5-μm-rated, 20-μm-rated, and 40-μm-rated, 5-μm-rated polyethylene filter elements are standard.
• Superior water removal up to 98% efficiency - free water.
• Removal of effluents via manual or automatic float drains.
• Superior pressure regulation - diaphragm type regulator.
• Self relieving design; large diaphragm sensing ratio; non-relieving optional.
• Optional pressure adjustment locking key; tamper resistant pressure setting.
• Optional Pressure gauge
LUBRICATOR
• Sight feed design; transparent dome to show oil delivery.
• External oil delivery adjusting knob, removable for tamper resistance.
• Color caps available for visual management systems. (Blue,red, yellow and grey).

Vanguard Modular - 108D
Part Number: MVCFDRL108D (1/4", 3/8", 1/2" and 3/4")
Filter and regulator consolidated in a single assembly (CFDR100); sight-feed lubricator (L28D); lockout valve (V35). Modular or inline mounting. 5-µm-rated polyethylene filter element; optional sintered bronze elements. Zinc bowls with clear nylon sight glass or polycarbonate plastic bowls with steel shatterguard. Internal automatic filter drain; optional manual drain, internal float drain, or external Hydro-Jector drain. Self-relieving diaphragm-type regulator; non-relieving optional. Pressure gauge. NPTF port threads; optional BSPP threads.

Vanguard Modular - 108W
Part Number: MVCFDRL108W (1/4", 3/8", 1/2" and 3/4")
Filter and regulator consolidated in a single assembly (CFDR100); wick-feed lubricator (L28W); lockout valve (V35). Modular or inline mounting. 5-µm-rated polyethylene filter element; optional sintered bronze elements. Zinc bowls with clear nylon sight glass or polycarbonate plastic bowls with steel shatterguard. Internal automatic filter drain; optional manual drain, internal float drain, or external Hydro-Jector drain. Self-relieving diaphragm-type regulator; non-relieving optional. Pressure gauge. NPTF port threads; optional BSPP threads.

380 SERIES Modular
Part Number: AAMV3A0B1A1 (3/8", 1/2" and 3/4")
Ambient/Media Temperature: Metal bowls: 4° to 79°C, Plastic bowls: 4° to 52°C
Bowls: 270ml capacity aluminum bowls with clear nylon sight glass or polycarbonate plastic bowls with steel shatterguard. Optional 450ml extended aluminum lubricator bowl with two clear nylon sight glasses.
Cap Colors: Filter/regulator, black only. Lubricator, accent grey; yellow, red, and blue optional.
Filter Drain: Internal automatic drain; optional manual drain, internal float drain, or Warrior electronic drain
Filter Element: 5-µm-rated polyethylene; optional 40-µm element.
Fluid Media: Compressed air.
Heads: Zinc
Inlet Pressure: Min: 15psig (1bar) with automatic drain, 30psig (2bar) with internal float drain, Metal bowls: 200psig (13.7bar) max, Plastic bowls: 150psig (10bar) max
Oil Adjustment: External; tamper-resistant
Outlet Pressure: Adjustable up to 125psig (8.6bar)
Pressure Adjustment Locking Key: Removable
Pressure Gauge: 0 to 200psig (14bar); 1/4 NPT ports front and rear
Regulator: Nylon dome, acetal knob
Seals: Nitrile
Sight Dome: Clear nylon
